F663001 A/B/C BNC Test Leads

F663001 A/B/C BNC Test Leads



  • Terminal Connector:4-Terminal Pair, BNC
  • DUT Connection:4-Terminal
  • Cable Length(approx.):0.5m/1m/2m (A/B/C, RG174)
  • Weight (approx.): 152g
  • Applicable Models: 6363~6367、6632、6630
  • Frequency:DC to 20MHz/10MHz/5MHz (A/B/C)
  • Max. Voltage:±200V peak max.(AC+DC)
  • Operating Temperature: 0°C to 55°C


  • Frequency/Cable Length
Model F663001 A F663001 B F663001 C
Freq. 20MHz 10MHz 5MHz
Cable Length 0.5m 1m 2m
