DC Bias Current Test System

6225+6632 is a high frequency test system for magnetic satureation of magnatic components. Maxinum freqwuency resonance is up to 30 MHz. Fulfill the application for 5G industry.

MICROTEST maximum current can be as high as 320A. Frequency response up to 10MHz. The 6632 offers current graphical scan to inspect I sat and I rms. Analyze the curve of temperature change and saturation of inductor to see if it would burnout due to the temperature. List mode function, customers may select multiple parameters by 1 setting, all the test results are shown at the same time.
DC Bias Current Test System
6225+6632 DC Bias Current Test System
6225+6632 DC Bias Current Test System
  • Current and frequency graphic scanning analysis
  • Frequency response 100Hz-30MHz
  • DC Bias Current Max.20A (6225)
  • DCR Measurement function
  • Built-in the Permeability-μr
  • Long-term consecutive maximum power output
  • Direct Handler interfaces control through Impedance Analyzer
  • Support meter mode and list mode, sweep mode
Inquiry Compare
6243+6632 DC Bias Current Test System
6243+6632 DC Bias Current Test System
  • Current and frequency graphic scanning analysis
  • Frequency response 100Hz-10MHz
  • DC Bias Current Max.320A (6243)
  • DCR Measurement function
  • Built-in the Permeability-μr
  • Long-term consecutive maximum power output
  • Direct Handler interfaces control through Impedance Analyzer
  • Support meter mode and list mode, sweep mode
Inquiry Compare
6240+6632 DC Bias Current Test System
6240+6632 DC Bias Current Test System
  • Current and frequency graphic scanning analysis
  • Frequency response 100Hz-3MHz
  • DC Bias Current Max.320A (6240)
  • DCR Measurement function
  • Built-in the Permeability-μr
  • Long-term consecutive maximum power output
  • Direct Handler interfaces control through Impedance Analyzer
  • Support meter mode and list mode, sweep mode
Inquiry Compare
6223+6632 DC Bias Current Test System
6223+6632 DC Bias Current Test System
  • Current and frequency graphic scanning analysis
  • Frequency response 100Hz-10MHz
  • DC Bias Current Max.120A (6223)
  • DCR Measurement function
  • Built-in the Permeability-μr
  • Long-term consecutive maximum power output
  • Direct Handler interfaces control through Impedance Analyzer
  • Support meter mode and list mode, sweep mode
Inquiry Compare
6220+6632 DC Bias Current Test System
6220+6632 DC Bias Current Test System
  • Current and frequency graphic scanning analysis
  • Frequency response 100Hz-3MHz
  • DC Bias Current Max.120A (6220)
  • DCR Measurement function
  • Built-in the Permeability-μr
  • Long-term consecutive maximum power output
  • Direct Handler interfaces control through Impedance Analyzer
  • Support meter mode and list mode, sweep mode
Inquiry Compare
6210+6632 DC Bias Current Test System
6210+6632 DC Bias Current Test System
  • Current and frequency graphic scanning analysis
  • Frequency response 100Hz-3MHz
  • DC Bias Current Max.60A (6210)
  • DCR Measurement function
  • Built-in the Permeability-μr
  • Long-term consecutive maximum power output
  • Direct Handler interfaces control through Impedance Analyzer
  • Support meter mode and list mode, sweep mode
Inquiry Compare
